Installed Power (kW): 2x40+40;2x2x40+40 ;2x100+40;2x150+75;2x160+75;2x170+75

Mining Height (m): 0.7~1.25;0.85~1.5;1.3~3.0

Coal Seam Inclination Angle (°): ≤35; ≤35

Coal Hardness (f): ≤3;≤3.5

Surface Height (mm): 550;640;1100

Minimum Dinting Depth (mm): 115;80;199

Draught Speed (m/min): 0~5; 0~5.5

Draught Force (kN): 150;168;358

Draught Form: Hydraulic chainless traction

Drum Diameter (mm): Ф670, Ф800;Ф800, Ф1000;Ф1250, Ф1400, Ф1600

Drum Speed (r/min): 91;85;46

Effective Cutting Depth (mm): 630, 800;630

Supply Voltage (V): 1140;1140

Operation Mode: Manual, Electronic Control, Remote Control of Ranging Arm

Dust Suppression Mode: Internal and External Spray

Design Production Capacity (t/h): 405;437;500

Maximum Non-detachable Dimension (mm): 3670x1185x505;2700x940x700

Maximum Non-detachable Weight (kg): 5500;3415

Total Weight (t): 8, 10;12;26

Match Feeding Machine Model: SGZ630; SGZ630, SGZ730
